Product Description
1ãrequirement Overview
Sludge dewatering belt filter press machine use international industry standards and following technical specifications for the design and manufacturing. Sludge dewatering machine for sludge thickening, dewatering, reduce the moisture content of the cake, easy to transport and final disposal of sludge, in order to dilute the sludge can be processed quickly to meet the technological needs, dewatering machine equipment has been widely used. And belt filter press with a compact, small footprint, low investment, etc. dewatering room.
2ãthe technical parameters of equipment operation
1 Working conditions
Installation site | In sludge dewatering equipment room |
Ambient temperature | -15ï42 |
Medium temperature | 5ï30 |
PH of the medium | 6ï9 |
Work system | 24h/d |
2 Technical parameters
Name | Unit | Value |
Qty | set | 1 |
Structure | -- | Concentration Dewatering integrated |
Filter with effective width | mm | 500-5000 |
treatment Capacity | m3/h | 1-20 |
Sludge | m3/h | 0.1-5 |
Moisture content of before sludge concentrated | % | 98-99.2 |
Flocculant dosage | g/kgMLSS | 3ï5 |
Sludge cake moisture content after dehydration | % | 80 |
Roller speed | r/min | 5ï30 |
Mechanical seal design life | h | 15000 |
Maximum flushing water consumption | m3/h | 15 |
Rinse water pressure | Mpa | 0.5 |
